Advantages and Features (In Detail)

• Rigid Construction and Low Wear: The frame and drive arrangement ensure high structural integrity and a long service life for components, even under intensive use.

• Manual Upper Shaft Adjustment: Allows the operator to precisely position the rolls for various profiles and material types.

• Flexible Drive Options: The standard speed range and several motor power variants allow the configuration to be tailored to specific tasks. An optional high-speed drive with needle-type bearings is available for increased loads.

• Versatility of Working Rollers: Schröder-Fasti produces high-precision hardened Rollers (flanging, swaging, wiring, folding, etc.). A universal set of roller pairs is available for most operations. The quality of the profile is largely determined by the correct selection of the "stop" in combination with the rollers.

• Convenient Control: Features a double foot pedal for bidirectional rotation (clockwise and counter-clockwise), enhancing both operator safety and ergonomics.

Standard Equipment

• Frame with a rigid column; manual adjustment of the upper shaft.

• Electromechanical drive version (standard speed range of 3–15 m/min).

• Double foot pedal (forward/reverse) or an equivalent control solution.

• Basic recommended set of working rollers—a universal 6-pair starter kit.

Options and Additional Modules

• Expanded Roller Set / Special Rollers: Schröder-Fasti offers standard and custom solutions for specific profiles.

• Sectional Stop: For processing complex contours and non-standard part shapes; a single-part stop is the alternative.

• High-Speed Drive (8–40 m/min): For this configuration, the shafts are mounted in needle bearings to withstand higher speeds and loads.

• Hydraulic Drive: Available as an option for specific executions.

Technical Specifications
