Advantages and Features

• Extreme Bending Force: Provides a powerful 440-ton capacity for demanding industrial heavy-duty applications.

• Generous Open Height and Throat Depth: Enhances flexibility during tool installation, allowing for the use of bulky tooling and the processing of large flanges.

• Large Ram Stroke: Sufficient to perform bends with high tool lifts or when a high degree of material clearance is required.

• Ultra-Rigid Construction: The heavy-duty frame is made of reinforced welded steel side frames to minimize deflection and ensure stable accuracy even under peak loads.

• Dual-Sided Roller Bearings: The tool beam moves on precision roller bearings on both sides, ensuring smooth travel, reduced friction/wear, and precise force distribution.

• User-Friendly Control: Equipped with a 2D graphical color touchscreen controller that simplifies programming and accelerates operator training.

Standard Equipment

• Color touchscreen controller with a 2D graphical interface.

• Independent Y1 and Y2 hydraulic cylinders with proportional valves for synchronized and precise beam control.

• Rigid welded steel side frames for enhanced strength and minimal deformation.

• Mechanical (or base) upper and lower tool clamping.

• Single-axis backgauge for fundamental workpiece positioning.

• Dual-sided beam roller bearings for smooth and accurate travel.

• Maximum hydraulic system pressure of 275 bar.

Options

• Advanced Multi-axis Backgauge: Additional axes (e.g., X-R or more) for complex positioning.

• Enhanced Safety Systems: Laser barriers, scanners, and protective screens in accordance with regional safety standards.

• Front Supports: Height-adjustable front support arms or supports mounted on linear guides.

• Special Tool Clamping: Integration of systems like WILA or other quick-clamping solutions.

• Custom Configurations: Options to adjust the open height and ram stroke based on specific customer production requirements.

Technical Specifications
