Features and Advantages

• Mobility and Lightness: Very lightweight ($4-6\text{ kg}$) and compact design, making it ideal for mobile use on construction/installation sites.

• Gas-Cooled Torch: The torch is Gas-cooled.

• Narrow Body: Ensures the ability to weld even under narrow conditions.

• Mechanical Electrode Tracking: Mechanically adjustable electrode tracking guarantees a constant electrode gap throughout the entire welding process.

• Application Versatility: The head can be used without additional accessories for a wide range of applications: pipe-to-pipe, pipe-to-fitting, and pipe-to-extrusion.

• Adjustable Torch: The gas-cooled, steplessly rotatable torch body can be adjusted in position and angle, allowing for the welding of not only classic $\mathbf{I}\text{-seams}$ but also fillet welds.

• Simple Operation: All necessary operational functions are available directly on the head via the integrated control panel in the handle.

• Tool-Free Adjustment: Basic mechanical settings can be performed without the use of tools.

• Surface Protection: The rotating tracking wheel protects the pipe surface, preventing damage during scanning.

Standard Equipment

• Mobile Head orbital weld head ($\mathbf{MH}3.0,\mathbf{MH}4.5,\text{ or }\mathbf{MH}6.6$).

• Integrated torch (gas-cooled).

• Mechanism for mechanical electrode tracking.

• Stepless adjustment of the clamping mechanism.

• Narrow head body.

• Reduction jaws (clamping inserts) (included to extend the clamping range).

• Integrated control panel in the handle.

Options

• Power Sources: Compatibility with $\mathbf{SW}$ and $\mathbf{Mobile}\mathbf{Welder}$ series power sources.

• Clamping Insert Sets: For precise clamping of pipes across the entire $\mathbf{OD}$ range.

• Various electrode lengths ($30-55\text{ mm}$).
