Rigid Gantry Structure with High-Precision Guides: Ensures stability and minimal positioning errors.

7-Axis CNC Control: Allows simultaneous movement of multiple axes, optimizing cutting trajectories.

Positioning Speed up to $75\text{ m/min}$: Dynamic drives ensure rapid mounting movements.

Adjustable Cutting Speed: Ranging from $200\text{ to }8,000\text{ mm/min}$, adaptable to material thickness and edge quality requirements.

Automatic Plasma Torch Height Control (Z-Axis): Maintains optimal distance between the torch and the sheet when dealing with imperfect surfaces.

Auto Clean Waste Container: The container moves with the cutting head, collects small parts, and is automatically unloaded.

Mobile Support Table: The roller-mounted table can be extended for loading/unloading, then returned to the working area.

Multi-functionality: In addition to plasma cutting, modules for marking, drilling, and thread tapping are available.

High-Performance Plasma Sources: Standard is Kjellberg HiFocus 160i, with the option for Hypertherm HyPerformance.

High Edge Quality and Repeatability: Guaranteed positioning accuracy ±0.05 mm; repeatability ±0.03 mm; angular tolerances ±0.2 mm.

Plasma Source: Kjellberg HiFocus 160i ($160\text{ A}$) — standard.

CNC Controller: With a 19′′ touchscreen display or equivalent interface with extended memory, USB, and LAN connectivity.

Automatic Torch Height Correction (Z-Axis): During cutting and piercing.

Auto Clean Vacuum / Waste Container: Follows the torch position to collect small parts.

Mobile Support Table: Mounted on rollers.

Marking Module: For scribing contours on the sheet.

Pneumatic Hold-Down: For clamping the sheet during operations.

Exchangeable Second Support Table: For more efficient loading/unloading.

Hypertherm HyPerformance Plasma Source: As an alternative to Kjellberg HiFocus.

Drilling / Tapping Head: Allows drilling up to $20\text{ mm}$ and tapping from $M3\text{ to }M16$.

High-Performance Filter / Ventilation System: For clean air, less smoke/dust.

Reinforced Cooling System: For extended operation under heavy loads.

Special Programming Modes: E.g., trajectory optimization, automatic sorting of small parts into containers.

Spare/Additional Plasma Head: Or spare inserts for quick replacement of consumables.

Advanced Safety Systems / Guarding: Additional covers, light barriers, safety sensors.

Additional Roller Table / Conveyor: For automatic unloading of finished parts.
