Advantages and Features

• Robust Massive Frame: Specifically designed to handle the stresses of thick metal processing.

• Up’n Down Technology: Bending in both directions eliminates additional handling operations.

• High Precision: Features motorized folding beam adjustment (170 mm) and bending center adjustment (+80/–15 mm).

• LED Tool Positioning: Visual indicators for rapid and accurate setup.

• Powerful Dual Drives: Clamping beam ($2\times 3.0\text{ kW}$) and folding beam ($2\times 5.5\text{ kW}$).

• Operational Convenience: Clamping beam stroke of up to 850 mm facilitates handling of large workpieces.

• Industry 4.0 Ready: Integration with CAM/ERP systems and DXF import capabilities.

Standard Equipment

• POS 2000 Professional: Mounted on a swivel arm, includes radius function and remote maintenance.

• Hydraulic Tool Clamping: For the clamping beam.

• Automatic Folding Beam: Featuring double-sided drive control.

• Backgauge System: U-shaped design, range 20–1600 mm, with pneumatically retractable sectors and ball roller table.

• Safety Systems: Light barriers, double foot switch, and RFID-protected doors.

• Note: Base configuration is supplied without tools.

Special Equipment and Options

• POS 3000: 3D graphical control with DXF import, bending simulation, and cycle time calculation.

• Schröder Unfold: Software for precise developed length (blank) calculations.

• Vacuum Suction System: Integrated into the backgauge (6 suction cups, software-controlled).

• Backgauge Extension: Options for J- or U-shaped tables up to 4000 mm.

• Additional Supports: Extra tables and pneumatic support arms.

• Industrial Protection: 30 kVA transformer and air conditioning for electrical cabinets.

Technical Specifications
