Advantages and Features

• Energy Efficiency: Energy consumption is significantly lower than hydraulic equivalents—offering up to 50% energy savings.

• Fast Bending Cycles: High ram speeds and dynamic characteristics allow for faster operation than traditional hydraulic machines.

• Rigid "O-Frame" Construction: This design ensures minimal deformation under load compared to standard C-frames, maintaining better alignment.

• High Positioning Accuracy: Equipped with two linear encoders that ensure ram positioning accuracy of ± 0.001 mm.

• Advanced Controller: Features a 19" multitouch screen with a user-friendly interface, supporting 2D design and CAD-CAM data import.

• Angle Control System: Includes active and dynamic angle measurement modes to compensate for material springback, ensuring consistent quality regardless of material thickness variations.

• Eco-Friendly & Low Maintenance: Oil-free operation eliminates hydraulic fluid, reducing maintenance costs and environmental impact.

• Integrated Safety: Optical protection systems (Laser / RapidBend / IRIS) combined with safety fencing.

Standard Equipment

• Controller: ESA S660W — 19" high-resolution multitouch screen with a 2D graphical management environment.

• Frame: Rigid O-frame construction for maximum structural stability.

• Encoders: Dual linear encoders for the ram with ± 0.001 mm precision.

Options

• Automatic Sheet Support (ASF): Front support arms that follow the sheet during the bending process; includes height adjustment and full NC integration.

• Backgauge Options: 2-axis, 4-axis, or 5-axis backgauges (X, X-R, Z1-Z2, etc.) for maximum positioning flexibility.

• Tool Clamping: Rapid mechanical or pneumatic upper tool clamping systems for fast setup changes.

• CNC Crowning: CNC-controlled table deformation compensation to ensure consistent angles across the entire bending length.
