ORBIWELD TP 1000 is the largest basic Open Arc Orbital Weld Head in the TP series, designed for welding large diameter pipes in the range of 120 mm to 275 mm (OD). The head is equipped with special clamping plates for reliable fixation on the pipe.
Features and Advantages
Large Range: Designed for welding pipes up to 275 mm.
Optimal Support: Standardly equipped with tool steel clamping plates to ensure optimal support on the pipe surface.
Ultra-Compact Design: Retains compactness due to the integrated drive motor.
Flexible Welding: The liquid-cooled, steplessly rotatable TIG torch allows for the welding of fillet welds.
Precise Adjustment: An adjustable guide for precise adjustment of the electrode position during welding.
Wire Welding (Option): The ability to retrofit with a Cold Wire feed unit.
Standard Equipment
ORBIWELD TP 1000 orbital weld head.
Liquid-cooled TIG torch.
Integrated control buttons.
Tool steel clamping plates for optimal support.
Hose pack with a length of 7.5 m.
Options
Cold Wire Feed Unit (KD3−100).
Technical Specifications
